BIOS:
- 256Mb AMI UEFI Legal BIOS with GUI support
Chipset płyty głównej:
AMD B850
Gniazdo procesora:
Socket AM5
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin)
Standard pamięci:
DDR5-8000+ (OC)
Wyposażenie dodatkowe:
- 1 x Standoff for M.2 Socket, - 1 x Thermistor Cable, - 2 x ASRock WiFi 2.4/5/6 GHz Antennas, - 2 x SATA Data Cables, - 2 x Screws for M.2 Sockets
Wymiary [S x W] (mm):
244 x 244
Zawiera baterię / akumulator:
Tak
Port Bluetooth:
Bluetooth V5.4
Maksymalna wielkość pamięci:
256 GB
Port LAN:
1x 2,5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125BG)
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax/be
Wbudowana karta graficzna:
Brak lub AMD RDNA™ 2 (zależy od procesora)
Obsługiwane typy procesorów:
AMD Ryzen™
Uwagi do procesora:
- Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors
Tryb pracy pamięci RAM:
Dual Channel
Uwagi do pamięci RAM:
Overclocking (EXPO) memory modules, Supports DDR5 ECC/non-ECC, Supports Extreme Memory Profile (XMP) and EXTended Profiles for
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s + 3x M.2
Uwagi do kontrolera SATA:
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280, - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x4, - 1 x M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x2, - 4x SATA3 6.0 Gb/s Connectors, (32 Gb/s) mode, (64 Gb/s) mode, 8000 (Phoenix 1) series processors and Gen4x2 with 8000 (Phoenix 2), Chipset:, CPU:, M2_1 is the first priority for M.2 installation., M2_1 will run at Gen5x4 with 9000 and 7000 series processors, Gen4x4 with, PCIe Gen5x4 (128 Gb/s) mode, Requires additional M.2 NVMe expansion cards to support RAID 10, series processors., Supports NVMe SSD as boot disks, Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices, Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Gniazda karty graficznej:
DisplayPort, HDMI
Uwagi do karty graficznej:
- 1x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max., - 1x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max., resolution up to 4K 120Hz
Zintegrowana karta dźwiękowa:
Realtek® ALC 1220 7.1-Channel High Definition Audio CODEC
Gniazda karty dźwiękowej:
3x Audio Jack, Wewnętrzne gniazdo audio przedniego panelu
Uwagi do karty dźwiękowej:
- Impedance Sensing on Rear Out port, - Individual PCB Layers for R/L Audio Channel, - Nahimic Audio
Złącza PCI Express x16:
1
Uwagi do złącz PCI:
- 1 x PCIe 4.0 x4 Slot (PCIE2), supports x4 mode, - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode, - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT, - 15µ Gold Contact in VGA PCIe Slot (PCIE1), 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2), Chipset:, CPU:, PCIe WiFi module, PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with, series processors., Supports NVMe SSD as boot disks
Uwagi do karty sieciowej:
- Optimized Default Setting for Game, Browser, and Streaming Modes, - Smart Auto Adjust Bandwidth Control, - User Customized Priority Control, - Visual Network Usage Statistics, - Visual User Friendly UI, Supports Dragon 2.5G LAN Software
Maksymalna ilość portów USB 2.0:
8
Maksymalna ilość portów USB 3.x:
9
Porty USB na panelu tylnym:
4x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 + 1x USB 3.1 Type-C
Gniazda USB na płycie głównej:
4x USB 2.0 + 4x USB 3.0 + 1x USB 3.0 Type-C
Port szeregowy (COM):
Brak
Port równoległy (LPT):
Brak
Inne porty i gniazda:
2x Antenna Ports, 2x CPU Fan connector(s), 3x Addressable LED Headers, 3x Chassis Fan Connectors, BIOS FlashBack button , Front Panel Audio Connector, Power LED and Speaker Header, RGB LED Header, SPI TPM header (14-1pin), Thermistor Cable Header
Ilość złącz pamięci DDR5:
4
Uwagi do WiFi / BT:
- 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology, - 802.11be 2x2 Wi-Fi 7 Module, - Supports 160MHz channel bandwidth with 6GHz frequency band, - Supports 2.4GHz/5GHz/6GHz frequency band, - Supports MU-MIMO, depend on the different regulation status of each country and region. It, driver available for Windows® 10. The availability of the 6GHz band will, software updates once available., The Wi-Fi 7 module is supported by Microsoft Windows® 11 only. There is no, will be activated (for supported countries) through Windows® Update and
